The structure is designed to hold 27pcs 400W mono solar panels. The solar panel will be connected to 1pc 10kW three phase on grid inverter to sell electricity.

The system is used for one Uruguay farm. The farm was powered by generator which produced a lot of noise and gasonline price almost killed the owner. They finally decided to use our 30kw solar system to replace the generator.  Generator only works as standby during rainy season when sunshine is not good enough. The system is composed of 60pcs 410W mono(10pcs in one string and 6 strings in parallel) 6pcs 5kw solar inverter parallelled to get 30kW, three phase output 12pcs 51.2V100AH rack type lifepo4 battery in parallel

The 150kW solar off grid system was installed in Tibet in High Altitude Area. It has been working continuously for 6 years. Everything works fine for the moment. The system is composed of 1pc 150kW power frequency inverter, 192pcs 2V1000AH gel batteries, 384pcs 250W poly solar panels.

This system is installed in one island of China. It will supply power to communication equipments and some home appliances. The main components are as follows: 180pcs 400W mono(15pcs in one string and 12 strings in parallel) 2pcs pv combiner boxes(6 inputs, 1 output) 2pcs 360V100A mppt solar charge controller 1 set 360V800AH Lifepo4 battery 1pc 100kw/360v three phase power frequency inverter solar panel bracket and other accessories

This 40kw off grid solar system is for a farm in South Africa. There is no grid, and the power was supplied by one generator which is noisy and the diesel cost is very high. The main components are as follows: 90pcs 320W mono(15pcs in one string and 6 strings in parallel) 1pc pv combiner box(6 inputs, 1output) 1pc 384V100A mppt solar charge controller 1pc 40kw three phase inverter 64pcs 12V200ah(32pcs in one string and 2 strings in parallel)

20kw off grid solar power system in Mongolia, the output voltage of inverter is 400V, supply power to living house in remote area. The components of this system 1pc 20kw three phase inverter(power frequency type) 1pcmppt solar charge controller 192V100A 32pcs 12V200AH Gel batteries(16pcs in one string and 2 strings in parallel) 48pcs 270W poly(8pcs in one string and 6 strings in parallel) 2pcs PV combiner boxes(3 inputs, 1 output).
